Beam Chain Type Rotator Flipping Machine Turning Machine

KeyWords

Beam Chain Type Rotator Flipping Machine Turning Machine

Categories	Accessories
Brand	YOMI CNC Cutting&Welding Machinery
Model	YM-LFZ-10
Motor Power	2.2*2KW
Electric power source	380V
Lifting strap length	8m*2
Insurance factor	1.2
Flip angle	360°
YM-LFZ-10	Max. lifting:10T
YM-LFZ-20	Max. lifting:20T
Update Time	Nov 21,2024

Contact Now

Favorites

Detail Information

Description

Beam Chain Type Rotator Flipping Machine Turning Machine

The machine adopts remote control mode, easy to operate and learn.

It can be flipped without being limited by the length, width, size and shape of the object.

Flip over large mechanisms without slipping or backspin, with high safety and runing smothly.

VEDIO

Technical Parameters

Item	Parameter		Remark
Model	YM-LFZ-10	YM-LFZ-20
Motor Power	2.2KW×2	4KW×2
Insurance factor	1.2times	1.2times
Sling length	8M×2/Pieces	8M×2/Pieces	Can be customized
Remote control battery	7#×2/Pieces	7#×2/Pieces
Flip angle	360°	360°
Machine size	2730×330×1300mm	2730×330×1300mm
Weight	1000KGs	1000KGs

Advantages compare with traditional device

Rotator machine VS Traditional method
Content	Rotator machine	Comparision
Turning method	Rotator machine	Use hooks, wire ropes, chains, etc.
Production efficiency	High Productivity	Low Productivity
Impact on quality	Rotating process is stable and runing with special protective tooling. Component surface is not damaged.	Damage to component surface; often bump during rotating, resulting in deformation of the profile.
Operability	Remote control operation, simple & easy to use (single person can do it)	Complex operation(requires many people to cooperate).
Safety	Low risks	High risks.
Usage cost	Low cost	large consumption of sling.

FEATURES

a. Remote control operation (easy to learn)

b. Stable operation, no skidding and no inversion when overturning large components

c. The turning angle is adjustable and can be turned 360°.

d. High security.

Used for the turning and short-distance lifting of complex heavy-duty steel structural parts;

Machine weight:1T,

Macine size:2730*330*1300mm

Use：Used for the turning and short-distance lifting of complex heavy-duty steel structural parts;

Max. lifting:10T;

Max. turn over Size (Section):1500mm*1500mm

Max. Turn over length:≤15M

turn over Speed:4000mm/min

Introduction

When manufacturing heavy or complex components, steel structure enterprises often face problems like low rotating efficiency, high risk and surface damage of components. Our company’s chain type beam rotator machine can solve above problems well.

①The equipment is operated by remote control, which has the characteristics of no slippage or reverse rotation of large-sized objects with special shapes.

② With 360° rotation function, it can be turned to any angle as required, easy to operate, flexible and reliable to use.

③The equipment is controlled by remote control, the operator can operate away from the flipped items, and has the characteristics of light up and down flipping freely.

④The equipment has the function of moving, without moving the large workpiece, the equipment can be moved to the site of the hanging overturned object and then overturned.

⑤The equipment adopts the suspension chain to fix the suspended overturned object, and the auxiliary chain or sling can also be replaced according to the irregular shape and size of the overturned object.

⑥ For special objects, the auxiliary grooved wheel and lifting belt can be replaced, so that the flipped objects can be lifted without traces of lifting.

⑦Using this device can improve the turnover efficiency and greatly reduce the cost for users.

⑧The suspension type turning machine can be used as a supporting tool for driving, and can also be turned over by a crane in the field. As long as the device can be lifted, it can be turned over freely, which is convenient and fast.

⑨The device can be turned over without being restricted by the length, width, size and shape of the object.

Application

It is used for the profile rotating and short-distance lifting of complex heavy-duty steel structural parts; (Picture are for reference)

Beam Rotator

When manufacturing heavy or complex components, steel structure enterprises often face problems like low turnover efficiency, high risk and surface damage of components. Our company’s chain turn-over machine can solve the above problems well.

Beam Rotator

Beam Rotator is used for lifting and turning over large objects in industries such as stone processing, electric power, ships, docks, machinery manufacturing steel structures, etc.
